Granular Mixing Machine

Name: Granular Mixing Machine
Brand: DHRUVESH MACHINERY
Price: 96000 INR
Availability: InStock

96000 INR/Unit

Get a Price/Quote

Product Details:

Frequency 50 Hz
Machine Type Granular Mixer
Features Stainless Steel Mixing Chamber, High Efficiency, Easy Maintenance
Control System PLC Controlled
Frame Type Welded Steel Frame
Cooling System Air Cooled
Accuracy 1% Mixing Uniformity
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Granular Mixing Machine Price And Quantity

Price 96000 INR/Unit
Minimum Order Quantity 1 Unit

Working Speed 30 rpm
Installation Type Floor Mounted
Material Grade 304 Stainless Steel Contact Parts
Hopper Capacity 500 Liters
Number of Mixing Arms 2
Input Hopper Size 450 mm Diameter
Discharge Method Bottom Discharge with Manual/Auto Option
Types of Granules Supported Plastic, Pharmaceutical, Fertilizer, Food Grade
Safety Features Overload Protection, Emergency Stop Switch
Mixing Time 8-15 minutes per batch
Finishing Corrosion Resistant
Service Support On-site Support Available
Max Particle Size 5 mm

Granular Mixing Machine Product Specifications

Accuracy 1% Mixing Uniformity
Dimension (L*W*H) 1200 x 900 x 1400 mm
Frame Type Welded Steel Frame
Cooling System Air Cooled
Operating Type Semi Automatic
Features Stainless Steel Mixing Chamber, High Efficiency, Easy Maintenance
Control System PLC Controlled
Product Type Granular Mixing Machine
Surface Treatment Paint Coated
Power Source Electric
Frequency 50 Hz
Pressure Atmospheric Pressure
Usage & Applications Mixing
Technology Mechanical Mixing
Machine Type Granular Mixer
Voltage 380 V
Weight (kg) 450 kg
Motor Power 3 kW
Model No GMX-500
Power 1-10HP Horsepower (HP)
Noise Level <75 dB
Operating Temperature 5C to 45C
Lubricating System Automatic
Color Blue & Silver
Power Rating 3 HP
Plastic Processed PE, PP, PVC, ABS, EVA, PET
Drive Gear Drive
Production Capacity 200-500 kg/h

Working Speed 30 rpm
Installation Type Floor Mounted
Material Grade 304 Stainless Steel Contact Parts
Hopper Capacity 500 Liters
Number of Mixing Arms 2
Input Hopper Size 450 mm Diameter
Discharge Method Bottom Discharge with Manual/Auto Option
Types of Granules Supported Plastic, Pharmaceutical, Fertilizer, Food Grade
Safety Features Overload Protection, Emergency Stop Switch
Mixing Time 8-15 minutes per batch
Finishing Corrosion Resistant
Service Support On-site Support Available
Max Particle Size 5 mm

Granular Mixing Machine Trade Information

Delivery Time 10 Days

Product Description

Buy Online the celebrated GMX-500 Granular Mixing Machine, now available at a price cut for a limited time! This first-class champion mixer is in demand for its exceptional performance-offering 30 rpm working speed, 8-15 minute batch mixing, and up to 500 liters hopper capacity. Built with 304 stainless steel contact parts and advanced safety features such as overload protection and an emergency stop switch. The machine supports various granules including plastic, pharmaceutical, fertilizer, and food grade, ensuring premium mixing results every time. As a top distributor, supplier, and manufacturer in India, we deliver on-site support and guaranteed satisfaction.

Exceptional Versatility & Advanced Features

The GMX-500 Granular Mixing Machine is optimized for a spectrum of industrial applications-from plastics and pharmaceuticals to fertilizers and food-grade products. With its atmospheric pressure operation, two robust mixing arms, and an easy-to-clean stainless steel chamber, the mixer ensures high efficiency, accurate 1% uniformity, and minimal noise (<75 dB). Semi-automatic operation and PLC control system make it user-friendly, while features like emergency stop and overload protection enhance workplace safety.

Efficient Export, Swift Delivery, and Secure Payments

Our acclaimed GMX-500 Granular Mixer boasts a consistent export track record to numerous international markets. With stock ready for dispatch, our trusted transport services ensure an estimated delivery time tailored to your location. We support a range of secure, flexible payment terms for hassle-free transactions. Whether you're ordering for a new facility or upgrading your production line, our team coordinates seamless logistics from our Indian distribution hub.

FAQ's of Granular Mixing Machine:

Q: How does the GMX-500 Granular Mixing Machine ensure uniform mixing?

A: The GMX-500 utilizes two mixing arms and a mechanical mixing process, offering a working speed of 30 rpm and PLC-controlled operations. This design achieves 1% mixing uniformity, ensuring consistency for every batch.

Q: What types of granules can be processed with this mixer?

A: The machine is engineered to handle a diverse array of granules such as plastic (PE, PP, PVC, ABS, EVA, PET), pharmaceutical, fertilizer, and food-grade materials, supporting particle sizes up to 5 mm.

Q: Where is this machine mainly exported to?

A: While we serve clients across India, our main export markets span Asia and Africa. Efficient logistics networks guarantee reliable delivery irrespective of destination.

Q: What safety features are integrated into the mixer?

A: The GMX-500 is equipped with overload protection, an emergency stop switch, and a robust welded steel frame, prioritizing user safety during operation.

Q: When is on-site service support available for this machine?

A: On-site service support is available as needed, coordinated by our technical team, ensuring swift installation, training, or troubleshooting post-delivery.

Q: How can the machine's discharge method be operated?

A: Operators have the flexibility to use either manual or automatic bottom discharge, streamlining material handling and minimizing downtime.
